Huis > producten > tubulaire vastlopende machine > China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine

Productgegevens

Plaats van herkomst: CHINA

Merknaam: Beyde

Certificering: CE

Modelnummer: 500/1+6

Betaling en verzendvoorwaarden

Min. bestelaantal: 1 set

Verpakking Details: Veiligheidscontainerverpakking

Levertijd: 90 dagen

Betalingscondities: L/c, d/a, d/p, t/t

Levering vermogen: 200 set/jaar

Vind de beste prijs
Productgegevens
Markeren:

500mm tubular stranding machine

,

big bearing tubular stranding machine

,

China manufacture tubular stranding machine

Gebruik:
Stranding
Kleur:
Volgens de eis van de klant
Naam:
Tubulaire Vastlopende Machine
Sollicitatie:
staal,aluminium,staaldraad
Draadmateriaal:
staal, koper
Centrale uitbetalingsspoel:
PN400-PN630
De grootte van de toepassingsspoel:
PND800-PND1600
Maximum naakte draaddiameter:
4 mm
Garantie:
12 maanden
Gebruik:
Stranding
Kleur:
Volgens de eis van de klant
Naam:
Tubulaire Vastlopende Machine
Sollicitatie:
staal,aluminium,staaldraad
Draadmateriaal:
staal, koper
Centrale uitbetalingsspoel:
PN400-PN630
De grootte van de toepassingsspoel:
PND800-PND1600
Maximum naakte draaddiameter:
4 mm
Garantie:
12 maanden
Productbeschrijving



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine



This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.

Application:
This high speed machines mainly used for stranding copper wire,aluminum wire, steel wire,ACSR and wire rope.Accompanied with taping head,it can used for insulation cores and some control cable stranding process.
Component:
Central pay-off. cage host,taping device (optional),capstan,take-up and traverse device,and electric control system.



Model 400 500 630
Inlet wire Dia.(mm) Conductor 1.5-3.5 1.8-4.0 2.0-5.0
Steel 1.0-2.5 1.5-3.0 1.8-4.0
Cores 1.2-3.5 1.5-5.0
Frame rotation speed(r/min) 700 600 400
Stranding Pitch(mm) 41-312 44-334
Linear Speed(m/min) 27-205.3 22-166.85 14-108.9
Capstan Dia.(mm) 800+1000 1000+1200 1000+1250
Size of tak-up bobbin PN1250 PN1600 PN1600



China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 0

China Manufacture Big Bearing Tubular Stranding Machine 500mm Model Tubular Stranding Machine 1

FAQ
1.Q: Where is your factory located? A: Our factory is located in HEJIAN CITY, HEBEI PROVINCE, CHINA,
we are near Beijing, Tianjin and Shijiazhuang air port, and CANGZHOU WEST high-speed railway station.
2.Q: What is the advantage about your company? A: Our company has skilled technical engineer and workers and professional production line.
3.Q: Why should l choose your products? A: We are direct manufacturer, we can ensure the stable product quality and provide in time service.
4.Q: The logo and the color can be customized? A: Yes
5.Q:What's your near sea loading port: Tianjin port
